Australian Monitor AMC+60 60W 4 Input Mixer Amplifier

Regular price $299.00 Sale

Australian Monitor AMC+60 AMC+ Series 4 XLR Microphone Inputs 250W 100V Output Amplifier.

The Australian Monitor AMC+60 delivers high quality audioreinforcement in a low cost 2 rack unit package.

The AMC+60 has 4 XLR microphone and dual RCA line inputs with input 1 having priority over inputs 2-4 (defeatable) and global 12VDC phantom power.

Features

  • 60 watts
  • 2 RU rack mountable chassis
  • 4 XLR microphone/dual RCA line inputs
  • 100 volt or 4 ohm output
  • Input 1 vox muting priority (internally defeat able)
  • Alert/Evac/Pre Announce/Bell tone board available
  • 12VDC phantom power



Specifications



    Output Power per Channel 60W Frequency Response 75Hz - 20kHz
    Output Mode 4 Ohm-100V THD+N < 0.5%
    Input Channels 4 MIC or Line Signal to Noise Ratio > 75dB
    Input Voltage 230Vac 50Hz Input Sensitivity MIC: 1mV - Line: 150mV
    Mounting 2RU Cooling Convection
    Warranty 5 years
    Product Dimensions (W x D x H) 482mm x 281mm x 88mm Shipping Dimensions (W x D x H) 534mm x 410mm x 198mm
    Net Weight 8.5 Kg Shipping Weight 13.5 Kg
    GTIN EAN 9323383010086
