GOBOZOOM-USB CHAUVET DJ GOBO PROJECTOR

OVERVIEW

Gobo Zoom USB is a super compact gobo projector with a manual zoom, and wireless connectivity in master/slave and DMX mode, thanks to its embedded D-Fi USB compatibility. Gobo Zoom USB includes 10 wedding-ready gobos. Gobo Zoom USB can be controlled without DMX using the optional IRC-6 remote (sold separately). Gobo Zoom USB accepts custom gobos, including patterns and messages easily printed on transparency film. Fits best in the CHS-40 VIP Gear Bag.

• Super-compact custom gobo projector, with built-in D-Fi USB compatibility that allows for instant wireless connectivity
• D-Fi USB compatibility for wireless Master/Slave or DMX control (sold separately)
• Control dimmer, gobo rotation and direction with the built-in digital display or optional IRC remove
• Manual zoom for short-throw or long-throw applications
• Includes 10 wedding ready gobos
• Access all functions via the optional IRC-6 remote
• User-configurable standalone operation provides excellent control without DMX
• Print your own custom gobos on transparency film
• Fits best in the CHS-40 VIP Gear Bag

SPEC

DMX Channels: 2
DMX Connectors: 3-pin XLR
Gobo Size: 25.74 mm outside, 19.38 mm max image, 1 mm max thickness
Light Source: 1 LED (cool white) 25 W, (6 A), 50,000 hours life expectancy
PWM Frequency: 1,200 Hz
Zoom Angle (manual): 17° to 28°
Illuminance: (17°) 3,075 lux @ 2 m
Illuminance:(28°) 1,121 lux @ 2 m
Power Linking: 13 units @ 120 V; 24 units @ 230 V
Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power and Current: 39 W, 0.3 A @ 240 V, 50 Hz
Weight: 2.1 kg
Size: 238 x 124 x 244 mm
Optional Controllers: IRC-6
Approvals: CE
