A true line array system encompassing advanced technology and refined Italian engineering – these are the principles behind MUSE, a new sound reinforcement solution from FBT that redefines the modern line array in terms of power, size, light weight, flexibility and ease of use. True modularity means that MUSE is ready for any application, from a small installation using two enclosures to a large outdoor concert deploying 16 speakers per hang.

Precision coverage vertical active array

600W + 300W RMS - 135dB SPL

• 2-way, compact bass-reflex line array system
• Two 250mm (10") woofers with 64mm (2.5") voice coils
• Two custom B&C HF compression drivers with 25mm (1") throats
• Precision waveguide delivering 90° of horizontal dispersion up to 18Khz
• Frequency response from 55Hz to 20KHz
• Onboard Class-D bi-amp system delivering 600Wrms and 300Wrms for LF and HF with switch-mode power supplies
• Onboard DSP processor with 8 EQ presets, adjustable HF level of +/- 5db for accurate amplitude shading
• Control panel with XLR input and link, preset control, HF level control, HP-filter and ground lift
• Strong birch plywood cabinet with integrated aluminium handles, hardware and fly-ware offering adjustable angling ranging from 0° to 10° in 1° increments
• Wide range of accessories to offer ultimate flexibility no matter whether your MUSE line array system is suspended or ground-stacked, plus a specially designed cover to guard against bad weather
• A comprehensive range of both powered and passive line arrays, 2-way speakers, subwoofers and low profile stage monitors.

Subline 218SA:

SUBLINE 218SA incorporates two 460mm B&C woofers and a 1200W class-D amplifier with a switch-mode power supply.

• Bass-reflex design Subwoofer
• 2 x 460mm (18”) high excursion woofer with 75mm (3”) voice coil, custom made for FBT by B&C
• Frequency response from 30Hz to 120Hz
• 1200W RMS Class D power amplifier with switch mode power supply
• DSP with 6 presets, 3 x EQ with 2 x LPF crossover settings, 6-step digital delay line
• Control panel with stereo XLR in/out, Volume. EQ presets, Delay, Phase reversal switch 0°-180°, 3 status LED indicators
• 18mm Baltic birch plywood enclosure with heavy duty coating
• 2 x M20 threads for stand pole mount and 4 x aluminum ergonomic FBT handles, optional wheels
• Provides additional low frequency extension when used along with MUSE 210LA active line array system
