Mipro ACT707SE Wireless Lapel & Beltpack Microphone System

$779.00 Sale

Product Description
Beltpack and lapel wireless mic package including ACT707SE 16 frequency 1/2 RU diversity receiver and ACT707TE belt-pack and MU53S lapel mic
ACT707SE Key Features
ACT-707SE is a half-rack receiver in a compact metal casing.
Reliable diversity reception for maximum range with dual "Pilotone & NoiseLock" circuit prevents interferences.
Bright and easy-to-read LED display shows numeric channel and RF/AF strengths.
Innovative "Noise" indicator indicates if the receiver is experiencing interference.
Press the "SCAN" button and the receiver will auto-scan and lock on to an open, interference-free frequency.
Then press the "ACT" button to automatically upload the receiver frequency to the transmitter.
Output level and dynamic range are accurately pre-adjusted to equal the microphone capsule's sensitivity, thus ensuring optimal performance of the system.
16 systems can be operated simultaneously in one frequency band.
Patented and meets worldwide wireless regulations and approvals.
ACT707SETE Key Features
Plastic Housing
LED indicator displays power on/off and battery status.
Compact, lightweight and streamline shape for easy wearing.
Impedance selectable switch for microphone or guitar, and built-in sensitivity level adjustor.
Industry standard mini-XLR 4-pin (TA4F) connector is utilized for quick and screw lock connection and accepts lavaliere, headworn microphone and guitar inputs with level adjustments.
Belt clip allows 360 degrees rotating to suit transmitter wearing.
World's first ACT (Automatic Channel Targeting) function provides rapid automatic channel setting.
Innovative "Photo-cell Coupling" high dynamic range and high fidelity modulation circuitry is capable of accepting high input level and less distortion.
Advanced efficient transmitting and low power consumption circuit design.
22 hour battery life per single 9V battery.
Professional quality ensures no impact-damage.
MU-53S Key Features
Featuring a smooth, warm, natural sound.
MU-53L features a high dynamic range and able to withstand a maximum SPL of 142 dB without distortion.
Supplied as standard with MIPRO's 4-pin mini XLR connector.
Available in black or beige colors and 150cm cable.
Ideal for speech applications, saxophones, brass and wind instruments.
Product Specs
ACT707SE
Main Frame Size
EIA standard 1/2-rack unit
Channels
Single-channel
Main Frame Construction
Metal frame, plastic panel
Receiver Module
Fixed
Display Status
LED indicator displays channel and RF/AF metering.
Oscillation Mode
PLL synthesized
Stability
±0.005% (-10~50℃)
Carrier Frequency Range
UHF 620~950MHz
Bandwidth
24MHz
Receiving Mode
Diversity receiving
Sensitivity
6dBμV, at S/N>80dB, 40KHz deviation
Max. Deviation Range
±68KHz, with level limiting
S/N Ratio
>105dB(A)
T.H.D.
Frequency Response
50Hz~18KHz±3dB, with high-pass filter
Maximum Output Level
Mic-level: -20dBV/100Ω, Line-level: -4dBV/5KΩ
Output Connectors
XLR balanced & 6.3Ø phone jack unbalanced. Multi-channel system can switch between separate or mixed output.
Audio Output Adjustment
The world's first wireless system with output level accurately pre-adjusted to equal to the microphone capsule sensitivity and ensure optimal performance.
Squelch
Innovative "PiloTone & NoiseLock" dual-squelch circuit.
AC Power Supply
External 90~264V AC switching power supply
DC Power Supply
0.5A, 12~15V DC
Dimensions
210(W)×44(H)×206(D)mm / 8.3(W)x1.7(H)x8.1(D)"
Weight
0.9kg / 2.0lbs
Matching Transmitters
ACT-707HE, ACT-707H, ACT-707TE, ACT-707T
Note
Specifications on carrier frequency range and maximum deviation vary to comply with regulations of different countries.
ACT707SEBP
Housing Material
Plastic
Oscillation Mode
PLL Synthesized
Carrier Frequency Range
UHF 620~950MHz
Bandwidth
24MHz
RF Output Power
10~30mW (or dependent on applicable country regulations)
Spurious Emissions
Max. Deviation Range
±68KHz, with compandor and level limiting.
Maximum Input Level
0dBV
Microphones
MU-53L, MU-55L, MU-53HN, MU-55HN
Input Connector
Mini-XLR connector
Battery
9V x 1 (alkaline)
Display Status
LED power and low battery warning
Dimensions
63(W)×105(H)x21(D)mm / 2.5(W)x4.1(H)x0.8(D)"
Weight
85g / 3.0oz
Note
Varied specifications on carrier frequency range, maximum deviation, RF output power and spurious emission to comply regulation of different countries.
MU53S
Capsule Module
10mmØ uni-directional condenser microphone
Frequency Response
50Hz~18KHz
Sensitivity
-46dBV±3dBV/Pa (0dB=1V/Pa)
Maximum SPL
142dB (1%THD, typical)
Connector
4-pin mini XLR or TA4F
Cable Length
150cm / 59"
Color
Black
Weight
Approx. 19g / 0.7oz
