Neutrik Loudspeaker Connector Socket, 2 Way, 40A
Neutrik Loudspeaker Connector Socket, 2 Way, 40A
Stock Levels are Not Indicated Online, Please Contact Us to Confirm Avaliability
Regular price
$7
Regular price
Sale price
$7
Unit price
per
Couldn't load pickup availability
Product Description
Product Details
speakON Lockable Loudspeaker Cable Plugs
Simplifies connection of professional loudspeaker/amplifier systems
Robust, versatile and easy to assemble
All contacts are "touch proof" to meet the test safety requirements of IEC65/IEC348
Terminations are solderless, with easy assembly, making the connectors field serviceable
Positive keying and latching on the 2-way version
90° 4-way version available
| Rated Current | 30 A rms continuous |
| Current per Contact | 40 A rms 1 min. |
| Operating Voltage | 250 Vac |
| Cable OD Range | 6 - 10mm (2 way) |
| 5 - 15mm (4 way) | |
| 8 - 20mm (8 way) | |
| Max. Wire Size per Contact | |
| Solid | 6mm², 10 awg |
| Stranded | 4mm², 12 awg |
| Operating Temperature | -30° C → +80° C |
